Bracket set Szanghaj bolt-through fixing termo

EHS2QXF41XX/KTXXXX
arrow_selector
  • additional mounting posts
  • round profile
  • complimentary with Szanghaj two-meter adjustable pull handle
Commercial Information
expand_more
Type bolt-through fixing termo
Safety / Security Information
expand_more
CE Applicable NO
Technical Information
expand_more
Product Length 83 mm
Product Width 45 mm
Shape right
Material Aluminum
Finish Polished anodised F8, black
Logistical Information
expand_more
Dimensions bulk package 260 x 55 x 35 mm
Mounting information
expand_more
Including Mounting Material YES
Assembly time 20 min
Recommended Mounting Materials
- pin: 4 pcs.
- thermal muffle: 2 pcs.
- hubcup: 2 pcs.
- uni sleeve: 2 pcs.
- Allen wrench
- set screw: 4 pcs.

Available mounting kits for pvc and aluminium doors.

Technical drawings
