Bracket set Szanghaj screwed insert fixing

EFS2QXI00XX/KXXXXX
arrow_selector

Complementary mounting Posts for 2-Meter pull handles

  • additional mounting posts
  • round profile
  • complimentary with Szanghaj two-meter adjustable pull handle
Commercial Information
expand_more
Type screwed insert fixing
Safety / Security Information
expand_more
CE Applicable NO
Technical Information
expand_more
Product Length 83 mm
Product Width 45 mm
Shape right
Material Aluminum
Finish Polished anodised F6, Inox
Logistical Information
expand_more
Dimensions small package 260 x 55 x 35 mm
Mounting information
expand_more
Including Mounting Material YES
Assembly time 20 min
Recommended Mounting Materials
- pin: 2 pcs.
- screwed insert: 2 pcs.
- uni sleeve: 2 pcs.
- Allen wrench
- set screw: 4 pcs.

Available mounting kits for pvc and aluminium doors.

Technical drawings
